10Pcs TRRS 3.5mm Right Angle PCB Audio Jack – 4 Pole PJ320A
10Pcs TRRS 3.5mm Right Angle PCB Audio Jack – 4 Pole PJ320A
10Pcs TRRS 3.5mm Right Angle PCB Audio Jack Connectors – 4 Pole, Through-Hole (PJ320A)
Upgrade your electronics projects with this pack of 10 high-quality TRRS 3.5mm right-angle audio jack connectors (model PJ320A / PJ-320A). Designed for through-hole PCB mounting, these 4-pole (TRRS) sockets feature a horizontal right-angle orientation, 4 contacts, no internal switch, and a rated voltage of 30V — making them a reliable choice for DIY audio builds, prototyping, and circuit repairs.
Each connector supports both stereo headphone output and microphone input, thanks to the TRRS (Tip-Ring-Ring-Sleeve) configuration. This versatility expands the functionality of your device without needing a separate mic jack.
Key Features
- Type: DIP / Through-Hole, Horizontal Right-Angle Mount
- Standard: TRRS – 4 Pole (Tip, Ring, Ring, Sleeve)
- Jack Size: 3.5mm (1/8")
- Contacts: 4 Conductor, No Internal Switch
- Rated Voltage: 30V
- Material: Rubber + Metal construction for durability
- Quantity: 10 pieces per pack — great value for hobbyists and engineers
- Compatibility: Connects headphones and external microphones for expanded device scalability
- Model: PJ320A / PJ-320A / PJ320 / PJ-320
Specifications
| Connector Type | 3.5mm TRRS Audio Jack |
| Mounting Style | Through-Hole (DIP), Right Angle |
| Number of Poles | 4 (TRRS) |
| Internal Switch | None |
| Rated Voltage | 30V |
| Material | Rubber + Metal |
| Quantity | 10 Pcs |
| Country of Origin | Made in Mainland China |
What's in the Box?
- 10 × TRRS 3.5mm Right-Angle PCB Audio Jack Connectors (PJ320A)
Perfect For
- DIY audio electronics projects
- PCB prototyping and circuit board repairs
- Custom headphone amplifiers and audio interfaces
- Replacing broken or worn audio jacks on devices
- Maker spaces, engineering labs, and hobbyist workshops
Note: Due to manual measurement, please allow a tolerance of 1–3mm. Monitor color settings may affect how product images appear; please refer to the actual item received.
