12V RFID Access Control Relay Module – Wiegand 26-44, 1000 Users

Take Control of Your Door Access with This Compact RFID Relay Module

The 12V RFID Access Control Mini Relay Module Controller Board is a powerful, standalone single-door security solution that supports both Wiegand 26–44 protocol and Touch Memory (DS1990A / TM) card reading modes. Ideal for offices, homes, warehouses, and other spaces that require reliable, flexible entry management — all without the need for complex networking.

Key Features

• Dual Card Reading Modes: Supports Wiegand 26–44 (D0/D1 output RFID readers) and Touch Memory (DS1990A) card readers for broad compatibility with existing access control hardware.
• Standalone Operation: No network connection required. Manages single-door entry and exit independently — simple to install and configure.
• 1,000-User Capacity: Stores credentials for up to 1,000 users, making it suitable for small to medium-sized installations.
• Admin Card Management: Comes with 2 management cards for easy permission allocation, user enrollment, and system administration.
• Versatile Compatibility: Can be connected to a wide variety of external RFID card readers or TM card readers that output D0/D1 Wiegand signals.
• Durable PC Material: Built from polycarbonate (PC) for long-lasting reliability in everyday environments.
• 12V DC Power Supply: Standard 12V input for easy integration with typical access control power setups.

Specifications

• Operating Voltage: 12V DC
• Supported Protocols: Wiegand 26–44, Touch Memory (DS1990A)
• User Storage: Up to 1,000 users
• Management Cards Included: 2
• Material: PC (Polycarbonate)
• Color: As shown
• Country of Origin: Made in Mainland China

Ideal Use Cases

This module is perfectly suited for:

• Office building entry points
• Residential doors and gates
• Warehouses and storage facilities
• Any single-door application requiring stable, high-compatibility access control

Package Contents

• 1× RFID Access Control Mini Relay Module Controller Board

Note: Only the above package content is included. Other products shown for illustration purposes are not included. Slight color differences may appear due to lighting and display settings. Measurement tolerance: ±1–3 cm.

You May Also Like

• 1pc Precision Japanese Double-Edged Hand Saw – SK5 Steel, Fine-Toothed for Carpentry and Gardening
• 10CM Wireless LED Motion Sensor Night Light – Type-C Rechargeable Cabinet Wardrobe Lamp
• 1pc Stainless Steel Gardening Shovel – Suitable for Soil Turning and Weed Removal

Learn more: OSHA guidance on hand and power tools

Frequently Asked Questions

Q: What card protocols does this RFID access control relay module support?

A: This module supports Wiegand 26–44 protocol (compatible with D0/D1 output RFID card readers) as well as Touch Memory (DS1990A / TM) card reading mode. This dual compatibility makes it highly versatile for integrating with a wide range of existing RFID or TM card readers.

Q: Does this module require a network or internet connection to operate?

A: No. This is a fully standalone access control system. It manages single-door entry and exit independently without requiring any network connection, making setup straightforward and reliable even in locations without network infrastructure.

Q: How many users can this access control module store?

A: The module supports up to 1,000 users. It also comes with 2 admin management cards for easy user enrollment, permission allocation, and system configuration.

Q: What power supply does this module require?

A: This relay module operates on a standard 12V DC power supply, which is compatible with most common access control and security system power setups.
