433MHz 4-Button Universal Garage Door Remote Duplicator
433MHz 4-Button Universal Garage Door Remote Duplicator
433MHz Universal 4-Button Garage Door Remote Control Duplicator
Take control of your garage, gate, or automated entryway with this compact and easy-to-use 433MHz Universal Remote Control Duplicator. Supporting fixed code, learning code, and rolling code formats, this 4-channel duplicator lets you clone your existing remote in seconds — no technical expertise required. Compatible with a wide range of RF-based systems including electric doors, automated curtains, lighting switches, and more.
Key Features
- 433 MHz RF Transmission — Reliable wireless communication with a range of 50–100 metres in open areas
- 4-Channel Operation — Copy and store up to 4 individual button codes from your original remote
- Universal Compatibility — Works with fixed code, learning code, and rolling code systems for garage doors, gates, lighting, electric doors, automated curtains, and switches
- Simple Copy Process — Just hold the original and duplicator remotes close together, press the matching buttons simultaneously, and the LED confirms the code has been learned
- Code Clear & Restore — Easily clear stored codes or restore previously saved codes using the built-in memory function
- Battery Included — Comes with a 27A 12V battery so it's ready to use straight out of the box
- No App Required — Standalone RF device; no smartphone or Wi-Fi needed
- Compact & Portable — Slim, lightweight design fits easily on a keychain or in a pocket
Specifications
| Frequency | 433 MHz |
| Channels | 4 |
| Wireless Communication | RF |
| Transmission Distance | 50–100 m (open area) |
| Battery | 27A 12V (included) |
| App Support | No |
| Compatible Uses | Garage doors, electric gates, lighting, automated curtains, switches |
| Country of Origin | Made in China |
How to Use
Step 1 — Clear Existing Codes
Press and hold the two top buttons simultaneously. Keep holding until the LED flashes briefly and then goes out. After 2 seconds, the LED will begin flashing again, confirming the codes have been cleared. To verify: press any button — if the LED flashes once and immediately turns off, the clear was successful.
Step 2 — Copy Your Remote
Hold your original remote in your left hand and the duplicator in your right. Bring them as close together as possible. Press the corresponding button on both remotes at the same time. The LED on the duplicator will flash continuously, indicating the code from your original remote has been successfully learned. Repeat for each of the remaining 3 buttons.
Step 3 — Restore Saved Codes
If codes are accidentally cleared, press and hold the two bottom buttons simultaneously. After 3 seconds, the LED will light up and then flash quickly, confirming that your previously stored codes have been restored.
You May Also Like
- 10CM Wireless LED Motion Sensor Night Light – Type-C Rechargeable Cabinet & Staircase Lamp
- Crystal Peony Float Ornament – Hand Woven Car Interior Rearview Decoration Pendant
- Precision Japanese Double-Edged Hand Saw – SK5 Steel, 6-Inch Portable Mini Blade
Learn more: OSHA on eye and face protection
Frequently Asked Questions
Q: What types of remote codes does this 433MHz duplicator support?
A: This universal duplicator supports fixed code, learning code, and rolling code formats commonly used in 433MHz RF systems for garage doors, electric gates, automated curtains, lighting switches, and more.
Q: Does the 433MHz remote duplicator come with a battery?
A: Yes! The duplicator includes a 27A 12V battery in the package, so it is ready to use as soon as you receive it — no additional purchases needed.
Q: How many remotes or channels can I store on this duplicator?
A: The duplicator features 4 independent channels, allowing you to copy and store up to 4 different button codes from your original remote control onto a single device.
Q: What is the transmission range of this remote control duplicator?
A: In an open area, the 433MHz duplicator provides a reliable transmission range of approximately 50 to 100 metres, making it suitable for most standard residential garage doors and gates.
Production & Packaging Notice
To maintain high stock availability and fast shipping times, our items are sourced from multiple verified manufacturing facilities. While the core quality, materials, and product specifications remain identical, you may notice slight variations in the packaging design, manufacturing origin, or the wording of the printed instructions.
