DC-DC Buck-Boost Converter Module — Stable 5V Output from 4.5–21V Input
The DC-DC Buck-Boost Module is a compact, high-efficiency power conversion board designed to deliver a rock-solid 5V output regardless of whether your input voltage is above, below, or equal to 5V. With a wide input range of 4.5–21V and a built-in 3A constant current limit, this module is a versatile solution for DIY electronics, battery-powered projects, LED driver circuits, and lithium battery management systems.
Made in Mainland China.
Key Features
- Wide Input Range: Accepts 4.5–21V (recommended 5–20V), compatible with a broad range of power sources and battery packs.
- True Buck-Boost Topology: Non-isolated PFM buck-boost design steps voltage up or down as needed — no dropouts when input approaches output voltage.
- 3A Adjustable Current Limit: User-definable output current from 0–3A (max 3A) with constant current output — ideal for LED driving, battery charging, and load-sensitive circuits.
- Lithium Battery Voltage Stabilization: Optimized for single and multi-cell lithium battery packs to help maintain stable voltage during charging and discharging cycles, extending cell service life.
- Comprehensive Protection: Built-in under-voltage, input/output current limiting, over-temperature, and short-circuit protection for safe, reliable operation.
- UART Control Interface: Supports external low-level trigger and UART (TX, RX, GND) commands for programmable, automated control.
- Low Output Ripple: <30mV output ripple at 460kHz switching frequency for clean, stable power delivery.
- Wide Operating Temperature: Functions reliably from -40°C to +85°C with natural air cooling.
Full Specifications
| Type | Non-Isolated Buck-Boost |
| Working Mode | PFM |
| Input Voltage | 4.5–21V (recommended 5–20V) |
| Output Voltage | 5V (±0.05V accuracy) |
| Input Current (Peak) | <10A |
| Output Current Limit | 0–3A (user-definable, max 3A) |
| Line Compensation | 50mV/A |
| Switching Frequency | 460kHz |
| Output Ripple | <30mV |
| Standby Current | <5mA |
| Control Interface | UART (TX, RX, GND) |
| Output Control | External low-level trigger / UART command |
| Operating Temperature | -40°C to +85°C |
| Cooling | Natural air |
| Color | Green |
| Material | PCB |
Package Contents
- 1 × DC-DC Buck-Boost Module
Note: Battery, charger, and PCB enclosure are not included. Slight color variations may occur due to lighting and display differences. Dimensional tolerance: ±1–3cm.
