P10 Outdoor Full Color LED Display Module – SMD3535 320×160mm
Upgrade your outdoor signage with this high-performance P10 Full Color LED Display Module. Built with advanced SMD3535 technology, this module delivers vivid, true-to-life colors with outstanding brightness — making it the ideal choice for storefronts, stadiums, event venues, advertising boards, and more. Made in Mainland China.
Key Features
- SMD3535 Technology: Delivers exceptional color accuracy and high-quality visuals even in direct sunlight.
- 10mm Pixel Pitch: Ensures sharp, clear image resolution for outdoor viewing distances.
- Ultra-High Brightness: Over 5,500 cd/m² keeps your display vibrant and readable in bright outdoor conditions.
- Wide 120° Viewing Angle: Both horizontal and vertical, ensuring excellent visibility from virtually any angle.
- 100,000-Hour Lifespan: Long-lasting durability and reliability for years of continuous use.
- 16-Bit Color Grayscale: Rich, smooth color gradients for stunning visual content.
- Universal Input Voltage: AC 110–220V (+10%, 50/60Hz) for worldwide compatibility.
Technical Specifications
| Module Number | P10 Outdoor LED Display Module |
| LED Type | SMD3535 |
| Arrangement | 1R1G1B (Full Color) |
| Pixel Pitch | 10mm |
| Module Size | 320 × 160mm |
| Drive Method | 1/4 Scan |
| Module Resolution | 32 × 16 = 512 Dots |
| Pixel Density | 10,000 Dots/m² |
| Input Voltage | AC 110–220V (+10%, 50/60Hz) |
| Color Grayscale | 16-bit |
| Brightness | >5,500 cd/m² |
| Viewing Angle | 120° (H) × 120° (V) |
| Lifespan | 100,000 hours |
| Color | Black |
| Material | Plastic |
Package Contents
- 1 × P10 Outdoor Full Color LED Display Module (320×160mm)
Note: Only the above item is included. Other products are not part of the package. Slight color variations may occur due to lighting and screen differences. Measurement tolerance is ±1–3cm.
You May Also Like
- 10CM Wireless LED Motion Sensor Night Light – Rechargeable Cabinet & Staircase Lamp
- Butterfly HOME Letter Mirror Acrylic Wall Stickers – Living Room Décor
Learn more: OSHA on eye and face protection
Frequently Asked Questions
Q: Is this P10 LED display module suitable for outdoor use?
A: Yes, this P10 LED display module is specifically designed for outdoor environments. With brightness exceeding 5,500 cd/m² and SMD3535 LEDs, it remains clearly visible even in direct sunlight, making it ideal for outdoor advertising signs, storefronts, stadiums, and event displays.
Q: What is the pixel pitch and why does it matter for an outdoor LED display?
A: This module features a 10mm pixel pitch (P10), which is the distance between individual LED pixels. A 10mm pitch is well-suited for outdoor displays viewed from several meters away, providing sharp, clear image resolution at typical outdoor viewing distances without unnecessary expense on closer-pitch modules.
Q: Can I connect multiple P10 modules together to build a larger screen?
A: Yes. P10 modules are designed to be tiled and connected together, allowing you to build a custom-sized LED display panel to fit your specific installation needs. Each module measures 320×160mm with a resolution of 32×16 dots, so you can scale your display by adding more modules.
Q: What input voltage does this LED module support?
A: This module supports a wide input voltage range of AC 110–220V (+10%) at 50/60Hz, making it compatible with power supplies in most countries worldwide.
